ALEKO AC-2000 SLIDING GATE OPERATOR
4
Fig.1 AC-2000 accessories
AC-2000 gate operator packing list
ytitnauQ metI .oN
1
Gate operator
1
2
Release key
2
3
Operator base (spare accessory)
1
4
Tighten bar
2
5
Block bracket
2
6
Sprocket cover
1
7
Screw for mounting driven sprocket bracket (M8X16)
4
8
Anchor bolt with nut
4
9
Driven sprocket bracket (left side & right side)
2
10
Block
2
11
Anchor
4
