Alemite 7786-A5 - Page 3

High-Pressure Grease Pump SER 7786-A5
Alemite, LLC 3 Revision (1-13)
Repair Kits
Part No. Kit Symbol Description Notes
394747-1 Kit, Major Repair Includes items on Figure 2-A and 2-B
393040-1 Kit, Minor Repair (for Body and Seal Group)
393623 Kit, Minor Repair (for Pump Tube Assembly) Includes items on Figure 2-A and 2-B
393530-5 Kit, Seal [includes five (5) of item number 16]
393530-6 Kit, Seal [includes five (5) of item number 18]
Item
No.
Part No. Description Qty Notes
Numeric Order
Part # (Item #)
1 323842 Bolt, Eye, 3/8 " NPTF (m) 1 10522 (6)
2 Motor Assembly, Air 1 See SER 323440-4 171009-13 (14)
3 328037 Connector, 3/4 " NPTF (m) 1
Model 7786-A5, -C
171009-33 (10)
4 328031 Coupler Air, 1/2 " NPTF (f) 1 171009-35 (11)
5 327706 Adapter, 1/2 " NPTF (f) 1 172190-5 (16)
6 10522 Plug, Pipe, 1/4 " NPTF (m) 1 172190-6 (18)
7 340120 Adapter, 1/2 " BSPP (f) x 1/2 " NPTF (m) 1 Model 7786-MA 323419 (8)
8 323419 Washer, 1.29 " OD 1 323440-4 (2)
9 324274 Bushing (Rubber) 1 323693 (21)
10 X171009-33 O-Ring, 1-13/16" ID x 2 " OD 1
Pack of Ten (10)
323786 (12)
11 X171009-35 O-Ring, 1-15/16" ID x 2-1/8 " OD 1 323787 (13)
12 323786 Body 1 323842 (1)
13 323787 Screw, Cap, Socket Head, 1/2 " - 13 3 324274 (9)
14 O-Ring, 1-3/16" ID x 1-5/16 " OD 1 327706 (5)
15 Spacer 1 328031 (4)
16 Seal, 0.812 " ID x 1.062 " OD 1 328037 (3)
17 Ring, Lantern (Brass) 1 332465 (22)
18 Seal, 0.812 " ID x 1.562 " OD 1 332466 (20)
19 337361 Washer, 1.55 " OD 1 333256 (23)
20 332466 Spacer 1 337361 (19)
21 323693 Gasket (Aluminum) 2 337362 (17)
22 332465 Washer, 1.93 " OD 1
337363 (15)
23
333256 Nut, Jam, 2.00 - 16 UN - 2B 1 340120 (7)
24
340122
Adapter, 3/4 " BSPP (f) x 3/4 " NPTF (m) 1 Model 7786-MA
340122 (24)
Legend:
Part numbers left blank (or in italics) are not available separately
designates a repair kit item
