22
Most handbrake wires will show +12V at rest when the ignition is on and
ground when you set the handbrake. However, if the handbrake wire shows
0V while the handbrake is at rest, you will need to add a relay. (See
diagram on page 12.)
Automatic transmission vehicle: Uncut (leave intact) the Violet Loop
Wire.
Manual transmission vehicle: Cut the Violet Loop Wire and tape
the end.
Note: The system is not recommended for the manual transmission
vehicles with removable tops.
Note: When installing this system on a vehicle with a manual transmission,
the following must be hooked up:
1. Brake Light Circuit and Handbrake Circuit. (See H5/2
BROWN/RED wire connection.)
2. Negative door pin switch (see H5/6 GREEN wire connection.) or positive
door pin switch (see H5/7 VIOLET wire connection.)
Note: Vehicles with a manual transmission must use Engine
Checking Tach. Or Engine Checking Oil Sensor. only. (See
Start Feature Programming # 2 - 2)
B: PROGRAMMING A REMOTE TRANSMITTER:
Note: The control module will only retain the last 4 remote transmitters
programmed. If the transmitter memory is exceeded, the security system
will start deleting transmitters from its memory in chronological order.
1. Turn the Ignition switch OFF and ON 3 times and then leave in
the ON position.
2. Within 15 seconds, press the valet/program switch 3 times and
on the 3
rd
, press and hold it in until 1 long chirp is heard and the LED
starts to flash, then release the valet/program switch. You are now
in the TRANSMITTER PROGRAMMING MODE.
3. Press and hold any button on the transmitter until (1) chirp from the
horn and (1) flash from parking lights confirms the first transmitter
is now programmed.
4. If you have additional transmitters (up to 4) that need to be programmed,
repeat step 3 for each transmitter.
AUTOMATIC OR MANUAL TRANSMISSION
