2
AL0-17-0103 Res Array 4X10K 1/10W 0603 1 E_R1
2
CN0420001302 Flat Cable 4Pin Pitch 2.0mm Si 1 E_J1
2
SWDC11B2020405 Switch Rotational Encode 20Pul 1 E_ENC1
1
TWPC10A00901 TOP Panel PCB Assembly
1
2
AL2-51-4401 Transistor 2N4401 NPN SOT-23 ( 13 Q1~6,8~10,14,15,20,21
2
AL2-51-4403 Transistor 2N4403 PNP SOT-23 1 Q7
2
AL2-62-0541 IC 74AHC541 OCTAL BUFFERS/DRIV 1 U2
2
AL2-62-0573 IC SN74AHC573DWR Octal Transpa 1 U1
2
AL7-20-0070 BEAD 120@100MHz 200mA±25% 0 2 L1,2
2
BALE48207-5A LED HOLDER 2 (D4,5)
2
CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7 11 C1~9,11,12
2
FCN1T0503001 FCN Down Touch ZIF SMD Pitch=0 1 J2
2
FCN1T1003001 FCN Down Touch 90° Pitch 1.0m 1 J1
2
LDL-2060GD Liquid-emitting Diode Green As 1 D4
2
LDL-2060ID Liquid-emitting Diode Red Asti 1 D5
2
PC10A009 TOP Pane PCB 2 Layer FR-4 1.6T 1 -
2
RS000008J05 RES 0 5% SMD 0805 11 R1,6~13,16,17
2
RS006808F05 RES 68 1% SMD 0805 1 R14
2
RS010K08F05 RES 10K 1% SMD 0805 14 R2,4,5,21~29,79,80
2
RS018008F05 RES 180 1% SMD 0805 1 R15
2
RS02K208F05 RES 2.2K 1% SMD 0805 4 R3,18,19,20
2
TE682000401 Pin Header 90° Pitch:2.0mm Si 1 J3
