Alesis Prolinear 720 - Page 26

LEVEL P/N DESCRIPTION QTY REF
AS4 BOM
..3 2-52-5252 DIODE MMBZ5252B24V 1 D2
..3 2-52-5257 DIODE MMBZ5257B 1 D1
..3 2-71-0532 IC NJM5532M 1 U7
..3 2-71-3079 IC MC33079 1 U6
..3 2-72-0339 IC LM339 1 U4
..3 2-75-1101 IC AL1101 1 U9
..3 2-75-1201 IC AL1201 1 U11
..3 2-77-0095 IC AL3102 1 U8
..3 3-03-0001 LED(TRI-STATE) 1 2(LED1)
..3 4-05-0021 XLR JACK 1 22(J7)
..3 4-15-0200 2P SIL CONNECTOR 2 J2,3
..3 4-15-0204 4P SIL CONNECTOR 1 J1
..3 4-15-1002 CONNECTOR(2P SOCKET) 1 J8
..3 4-70-0027 5P CONNECTOR 260MM 1 (J5)
..3 7-01-0024 CRYSTAL 12.288MHZ 1 X1
..3 9-40-0297 PCB 1
..3 9-61-0110 MCU(2-70-0909) 1 U12
..3
CS104K10005X7R CAPACITOR 0.1UF/100V SMD 6 C9,10,16,17,29,31
..3 JW5206T JUMPING WIRE 37 J101~J137
..3 NUT0103IZI NUT 3M/M 1 (U10)
..3 PT01104803 LED FIXED 4.8X3MM 1 4(LED1)
..3 SC0308RIZI SCREW 1 (U10)
..3 TE10200702 CONNECTOR(7P SOCKET) 1 J9
..3 TE622000201 SOCKET (2P 90 度 ) 1 3(J6)
..3 TE812000511 TERMINAL (5P) 2 J4,5
..3 WS663309IC WASHER (3M/M SPRING ) 1 (U10)
