X4_BOM_AIMS_2001-12-28_Uncosted.xls
Part.Number Description Qty Per Ref.Designator ECN
X4-UL MIXER 16-CHANNEL RACK/TABLE-TOP STUDIO 32 X4 - UL 1
7-04-0010 FUSE 1.25A 250V 5x20mm T 1
7-40-0011 TRANSFORMER TORROID POWER 100/120V X4 1
7-41-0005 CABLE POWER UL/CSA SJT 1
7-51-0000-A CARD WARRANTY DOMESTIC-ONLY - REV A 1
7-51-1217 SHEET SERVICE-CENTER-CONTACTS 8.5 x 11" 1
7-51-1219 SHEET "WELCOME TO ALESIS FAMILY" 5 x 8" 1
7-53-0001 STICKER BUMPER ALESIS 1
7-53-0018 STICKER QC W/ MFR DATE (UL APPROVED) 1
7-53-0106 STICKER RATINGS/FUSE/UL/120V X4 1
X4-AS MIXER 16-CHANNEL RACK/TABLE-TOP STUDIO 32 X4 - AS 1
7-04-0011 FUSE 630mA 250V 5x20mm T TIME-LAG 1
7-40-0012 TRANSFORMER TORROID POWER 220/240V X4 1
7-41-0003 CABLE POWER AS 1
7-53-0111 STICKER RATINGS/FUSE/220V-COUNTRIES X4 1
X4-EU MIXER 16-CHANNEL RACK/TABLE-TOP STUDIO 32 X4 - EU 1
7-04-0011 FUSE 630mA 250V 5x20mm T TIME-LAG 1
7-53-0107 STICKER RATINGS/FUSE/CE/230V X4 1
7-40-0012 TRANSFORMER TORROID POWER 220/240V X4 1
7-41-0002 CABLE POWER EU 1
7-53-0107 STICKER RATINGS/FUSE/CE/230V X4 1
X4-UK MIXER 16-CHANNEL RACK/TABLE-TOP STUDIO 32 X4 - UK 1
7-04-0011 FUSE 630mA 250V 5x20mm T TIME-LAG 1
7-40-0012 TRANSFORMER TORROID POWER 220/240V X4 1
7-41-0004 CABLE POWER UK 1
7-51-0030 TAG POWER-UP HANGING - REV A 1
7-53-0107 STICKER RATINGS/FUSE/CE/230V X4 1
X4 MIXER 16-CHANNEL RACK/TABLE-TOP STUDIO 32 X4 1
4-09-0008 CON PWR IEC (SNAP IN) W/FUSE HOLDER 1
4-19-0108 CABLE SIL 8-PIN-TO-4-PIN (2X) 4mm 620mm X4 1 GREEN wire to Pin4, connects to a ground opening by R140
4-19-0201
CABLE 1-PIN 18AWG BLUE 510mm 300V F-B SPADE-
TINNED
1 IEC TO J4
4-19-0301
CABLE 1-PIN 18AWG BROWN 75mm 300V F-B SPADE-
TINNED
1 IEC TO POWER SWITCH
4-19-0401
CABLE 1-PIN 18AWG PURPLE 425mm 300V F-F SPADE-
SPADE
1 PHANTOM-SWITCH TO J10 719602
4-19-1318 WIRE 1-PIN 120mm GREEN TINNED STRIPPED 1 IEC TO CHASSIC GND
4-50-0032
WIRE 18AWG 425mm GREEN W/YELLOW STRANDED RING-
TO-TINNED
1 POWER-PCB TO CHASSIS-GND
4-51-4500 WIRE JUMPER 15AWG 450mm 300V STRANDED 1 PIN of R200 on the main PCB, to J2 on the P/S PCB
5-00-0027 SCREW M3 x 5mm PPZ 4 POWER-SUPPLY PCB MOUNTING
5-00-0048 SCREW M3 x 6MM PHIL-SLOT TRUSS BLK 24 BOTTOM-PANEL TO TOP-PANEL
5-00-0126 SCREW 2.6 x 5mm PPB MACHINE 22 LED-PCB TO MAIN PCB STANDOFFS, MAIN PCB STANDOFFS TO F/P
5-00-0130 SCREW 6-32 x 1/2" PPB 1WAY 1 CHASSIS GND
alesis Confidential
4/9/2002 Page 1
