X4_BOM_AIMS_2001-12-28_Uncosted.xls
9-23-1077 STRIP GREASE 438.30mm X4 1
9-79-0184-C ASSY PCB METER 1
9-79-1259-C ASSY PCB MAIN X4 1
0-00-0103 RES 10K OHM 1/8W 5% 101
(8)R21, (16)R24, (16)R25, (16)R28, (16)R44, (16)R45, (1)R87, (1)R88, (1)R89, (1)R90, (1)R98, (3)R125, (3)R126,
(1)R142A, (1)R147A
0-00-0104 RES 100K OHM 1/8W 5% 54 (8)R2, (16)R3, (16)R5, (8)R55, (1)R103, (1)R104, (1)R105, (1)R106, (1)R110, (1)R112
0-00-0112 RES 1.1K OHM 1/8W 5% 31 (16)R35, (15)R36
0-00-0151 RES 150 OHM 1/8W 5% 16 R4
0-00-0152 RES 1.5K OHM 1/8W 5% 2 R201
0-00-0203 RES 20K OHM 1/8W 5% 2 R93, R94
0-00-0204 RES 200K OHM 1/8W 5% 1 R97
0-00-0222 RES 2.2K OHM 1/8W 5% 1 R59
0-00-0331 RES 330 OHM 1/8W 5% 2 R86, R124
0-00-0332 RES 3.3K OHM 1/8W 5% 1 R136A
0-00-0470 RES 47 OHM 1/8W 5% 8 R7A
0-00-0472 RES 4.7K OHM 1/8W 5% 14 (8)R6A, (1)R71, (1)R73, (2)R85, (1)R137A, (1)R138A
0-00-0512 RES 5.1K OHM 1/8W 5% 8 R10A
0-00-0562 RES 5.6K OHM 1/8W 5% 2 (1)R92, (1)R95
0-00-0563 RES 56K OHM 1/8W 5% 2 R111, R113
0-00-0622 RES 6.2K OHM 1/8W 5% 4 (4)R134
0-00-0751 RES 750 OHM 1/8W 5% 1 (1)R67
0-00-0752 RES 7.5K OHM 1/8W 5% 9 (6)R80, (3)R81
0-01-1002 RES 10.0K OHM 1/8W 1% 4 R99-102
0-01-1500 RES 150 OHM 1/8W 1% 12 (1)R91, (1)R96, (1)R116, (1)R117, (4)R127, (4)R128
0-01-9311 RES 9.31K OHM 1/8W 1% 8 (4)R129, (4)R130
0-03-0432 RES 4.3K OHM 1/4W 5% 2 R114, R115
0-03-0821 RES 820 OHM 1/4W 5% 16 (16)R42
0-09-0001 POT 5KY SINGLE 16 R1-16
0-09-0007 POT 5KB SINGLE C-DET 32 (16)R8, (16)R11
alesis Confidential
4/9/2002 Page 3
