Alesis Surge Mesh Kit User Manual

alesis.com
Manual Version 1.1
Connection Diagram Schema dei collegamenti
Diagrama de conexión Anschlussübersicht
Schéma d’installation
A
(4)
(3)
(2)
(3)
Box Contents Contenu de la boîte Lieferumfang
Contenido de la caja Contenuti della confezione
(2)
(2)
B C D
E F G H
I J K L
M N
O P
Q R
S T
U V W X
hi-hat
control
hi-hat
snare
kick
tom 1
tom 3
ride
crash
tom 2
8 in. / 20 cm 10 in. / 25 cm
10 in. / 25 cm
Q
R
8 in. / 20 cm
(2)

Alesis Surge Mesh Kit Specifications

General

Type	Electronic Drum Kit
Hi-Hat Pedal	Included
USB	USB-MIDI
Metronome	Yes
Sequencer	Yes
Built-in Coaching Features	Yes
Kick Pad	8-inch mesh
Cymbals	10-inch crash, ride, and hi-hat cymbals
Drum Module	Alesis Surge Drum Module
Kits	40 Kits (24 Preset + 16 User)
Outputs	1/8-inch Headphones
Connectivity	MIDI, USB
Power Supply	9V DC, 500mA, center-positive
Effects	Reverb, 3-Band EQ
Module Trigger Inputs	10
Module Analog Inputs	1/8-inch stereo aux input
Module Analog Outputs	1/8-inch headphone output
Headphones	1/8-inch headphone output
Module MIDI I/O	In/Out
Snare Pad	10-inch dual-zone mesh pad
