Connecting the X2
30 X2 Reference Manual
Examples of Connections
The X2 may be easily interfaced with most other professional recording and audio
equipment. All inputs and outputs, with the exception of the microphone inputs,
use 1/4" jacks. The microphone inputs are standard balanced XLR type jacks.
Input Connector Type
Mic Inputs XLR Balanced
Line Inputs 1/4" TRS Unbalanced or Balanced
Tape Send (Direct) 1/4" Mono Unbalanced
Tape In 1/4" TRS Unbalanced or Balanced
Inserts 1/4" TRS Unbalanced
Tape I/O 56 pin ELCO Balanced
Aux Sends 1/4" Mono Unbalanced
Aux Returns 1/4" Mono Unbalanced
Group Outs 1/4" Mono Unbalanced
Group Inserts 1/4" TRS Unbalanced
Master Outs 1/4" TRS Unbalanced or Balanced
Master Inserts 1/4" TRS Unbalanced
Studio Outs 1/4" Mono Unbalanced
Control Room Outs 1/4" TRS Unbalanced or Balanced
Ext. In 1 and 2 1/4" Mono Unbalanced
Headphone 1/4" TRS Unbalanced
MIDI In, Out and Thru 5 pin DIN N/A
ADAT Sync In 9 pin D N/A
