01
Remove the bolt from the headlight,
then adjust the headlight and front
fender to the correct position and
tighten the bolts
02
Turn the bike upside down, adjust
the height of the seat and rotate
the angle of the LED display to avoid
direct contact with the ground
03
Remove the fork protector.
This can be removed and discarded
PART 3: HEADLIGHT & FRONT WHEEL ASSEMBLY
04
Put the wheel in the front fork disc
brake disc alignment clamp card slot
05
Insert the front wheel for quick re-
lease. Adjust the screw pressure
06
Lock the front wheel quick release.
Quick release installation is now
complete
18
ALIEN E-BIKES USER MANUAL
