Version 1.01

Part names and functions

Front side of the tool

1 LCD Display

Touch screen display to use the software embedded in the tool.

Upper side of the tool

1 USB connector

Connect the tool to the computer.

2 Cable connector

Connect the cable supplied with the tool.
