DP100 Digital Power User Manual
⚫ Various complete protection circuit, safer to use
⚫ Support multiple ( ≤ 3) devices in series to achieve higher voltage output or
positive-negative voltage output
⚫ USB-A interface host mode (USBH) supports output 5V/1A, supports wired/wireless
mouse driver
⚫ USB-A interface slave mode (USBD) supports communication with the PC and supports
firmware upgrade
⚫ Rich display, using 0.96-inch 160*80 high-definition IPS screen, the display content is
more delicate
⚫ Customized mold, humanized angle design of display and control panel, convenient for
users to operate and observe. Small size, easy to carry
2，Technical Parameter
Items
Description
Input parametres
Input voltage range：DC5.0~32V，100mA~5A
Supports PD/QC charger and power bank
Output parametres
4.0mm banana plug interface: 0~30V，0~5A，100W(Max)
USB-A interface (USBH): 5V/1A(Input>5.5V/1A)
Setting resolution
Output voltage: 10mV
Output current: 1mA
Setting accuracy
Output voltage: ≤ 0.1% ± 5mV
Output current: ≤ 0.1% ± 3mA
Readback resolution
Input voltage: 0.01V
Output voltage: 0.01V
Output current: 0.001A
Readback accuracy
Input voltage: ≤ 0.2% ± 10mV
Output voltage: ≤ 0.1% ± 10mV
Output current: ≤ 0.1% ± 5mA
Load regulation
Voltage: ≤ 0.05% ± 5mV
Current: ≤ 0.1% ± 3mA
Power regulation
Voltage: ≤ 0.05% ± 5mV
Current: ≤ 0.1% ± 3mA
Ripple and Noise
Output voltage: ≤ 2mVrms, 10mVp-p
Output current: ≤ 1mArms, 3mAp-p
Temperature coefficient
of output
Output voltage: ≤ 200ppm
Output current: ≤ 200ppm
Full load efficiency
≤97% @100W(30V, 3.334A)
Working environment
0℃~40℃，0~75%RH
Size and weight
100.4mm*62.2mm*17.2mm / 95g
Table1.1 Characteristic
