DS100 Mini Oscilloscope User Manual
Main Features
Model
DS100
Coupling
AC/DC
Channel
2
Auto Set
Support
Screen
3.5-inch IPS
Quick Center
Support
Resolution
480*320
Save Waveform
bmp or csv
Analog
Bandwidth
50M
Max. Waveform
Capture Rate
500 wfms/s
Sample Rate
250MSa/S
Auto
Measurement
20
Channel
Isolation
>40dB
Measurement
Accuracy
±2%
Rise Time
<7ns
Frequency
Accuracy
±1‰
Memory Depth
128Kpts
Waveform
Generator
Square/Sine/Triangle/S
awtooth
Input
Impedance
1MΩ
Waveform
Frequency
Sine/Triangle/
Sawtooth
1Hz~50KHz@3V Vp-p
Square
1Hz~10MHz@3V Vp-p
Time Scale
8ns~50s
Firmware
Upgrade
Support
Vertical Scale
10mV/div~100V/div
Language
Simplified Chinese/
Traditional Chinese/
English
Maximum
Measurement
Voltage Range
±40V（@X1）
±400V（@X10）
±4kV（@X100）
±40kV（@X1000）
Interface
MCX（Probe）
USB（ Charging and
Communication ）
Sweep Mode
Auto/Normal/Single
Battery Life
≈7h
Trigger Type
Rising/Falling
Charging Time
≈3h（USB）
Timebase Mode
YT/XY/ROLL
Net Weight
109g
Persistence
Min/1 sec/Infinite
Dimensions
100mm*58mm*15mm
