PCI-Express graphics card installation matrix
850 W power-supply unit
Table 13. PCI-Express graphics card installation matrix
Single graphics Dual graphics Triple graphics Quad graphics
Slot installation Slot 1 Slot 1 and Slot 4
Not supported Not supported
Power connector
label
PCIE1 PCIE1 and PCIE3
Primary output Slot 1 Slot 4
1500 W power-supply unit
Table 14. PCI-Express graphics card installation matrix
Single graphics Dual graphics Triple graphics Quad graphics
Slot installation Slot 1 Slot 1 and Slot 4 Slot 1, Slot 4 and Slot 7 Slot 1, Slot 3, Slot 5 and
Slot 7
Power connector label VGA1 VGA1 and VGA2 VGA1 and VGA2 and
VGA3
VGA1 and VGA2 and
VGA3 and VGA4
Primary output Slot 1 Slot 4 Slot 7 Slot 7
16
