Alienware m15 R6 User Manual

Storage
This section lists the storage options on your Alienware m15 R6.
Your Alienware m15 R6 supports one of the following storage configurations:
● One M.2 solid-state drive
● Two M.2 solid-state drives
The primary drive of your Alienware m15 R6 varies with the storage configuration. For computers:
● with a M.2 drive, the M.2 drive is the primary drive
● with two M.2 drives, one of the M.2 drives is the primary drive
Table 10. Storage specifications
Storage type Interface type Capacity
One M.2 2230 solid-state drive PCIe Gen3 x4 NVMe, up to 32 Gbps Up to 512 GB
One M.2 2280 solid-state drive PCIe Gen3 x4 NVMe, up to 32 Gbps Up to 1 TB
One M.2 2280 solid-state drive PCIe Gen4 x4 NVMe, up to 32 Gbps Up to 2 TB
Keyboard
The following table lists the keyboard specifications of your Alienware m15 R6.
Table 11. Keyboard specifications
Description Values
Keyboard type
● 4-zone RGB backlit rubber dome keyboard
● RGB per key backlit Cherry mechanical keyboard
Keyboard layout
QWERTY
Number of keys
● United States and Canada: 85 keys
● United Kingdom: 86 keys
● Japan: 89 keys
Keyboard size
X=19.05 mm key pitch
Y=19.05 mm key pitch
Keyboard shortcuts
Some keys on your keyboard have two symbols on them. These
keys can be used to type alternate characters or to perform
secondary functions. To type the alternate character, press Shift
and the desired key. To perform secondary functions, press Fn
and the desired key.
NOTE: You can define the primary behavior of the function
keys (F1–F12) changing Function Key Behavior in BIOS
setup program.
For more information, see keyboard shortcuts. Keyboard
shortcuts
14

Alienware m15 R6 Specifications

General

Color name	Dark side of the moon
Form factor	Clamshell
Product type	Laptop
Product color	Gray
Market positioning	Gaming
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	3200 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
Motherboard chipset	Intel HM570
NVMe	Yes
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express
Storage media	SSD
SSD form factor	M.2
Card reader integrated	No
Total storage capacity	1000 GB
Number of SSDs installed	1
Battery weight	340 g
Battery voltage	13.35 V
Battery capacity	86 Wh
Battery recharge time	3 h
Number of battery cells	6
AC adapter power	- W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Panel type	WVA
Color gamut	99 %
Pixel density	188.3 ppi
RGB color space	DCI-P3
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	400 cd/m²
Native aspect ratio	16:9
Maximum refresh rate	240 Hz
NTSC coverage (typical)	19 %
Contrast ratio (typical)	400:1
Audio chip	Realtek ALC3254
Audio system	Nahimic 3D
Speaker power	2 W
Number of microphones	2
Front camera HD type	HD
Video capturing speed	30 fps
Front camera resolution	1280 x 720 pixels
Front camera resolution (numeric)	0.92 MP
Operating shock	140 G
Operating altitude	0 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	0 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	50 - 90 %
Antenna type	2x2
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Killer Wireless-AX 1650
Wi-Fi data rate (max)	2400 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
WLAN controller manufacturer	Killer
Charging port type	DC-in jack
USB 2.0 ports quantity	-
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Keyboard language	German
Operating system architecture	64-bit
Cables included	AC
Processor cache	24 MB
Processor cores	8
Processor model	i7-11800H
Processor family	Intel® Core™ i7
Processor frequency	- GHz
Processor manufacturer	Intel
Processor boost frequency	4.6 GHz
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 3070
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
Package depth	553 mm
Package width	76 mm
Package height	345.5 mm
Package weight	4667 g
Package material	Corrugated cardboard
Corrugated cardboard content per package	839.7 g
Wheat straw molded pulp content per package	0 g
Corrugated cardboard content per box for accessories	100.5 g
Corrugated cardboard content per shipping (inner) case	582.8 g
Corrugated cardboard content per sleeve for accessories	156.4 g
Pallet width	1000 mm
Pallet length	1200 mm
Pallet weight	386027 g
Quantity per pallet	81 pc(s)
Pallet volume weight	235300 g
Quantity per pallet layer	27 pc(s)
Number of layers per pallet	3 pc(s)
Maximum number of stacking cartons	6 pc(s)
Quantity per intermodal container (20ft)	1350 pc(s)
Quantity per intermodal container (40ft, HC)	3402 pc(s)
EPEAT rating	100 %

Weight and Dimensions

Depth	272.5 mm
Width	356.2 mm
Weight	2690 g
Height (rear)	19.25 mm
Height (front)	12 mm
