Alienware M18X User Manual

34
CHAPTER 3: USING YOUR LAPTOP
Advanced Menu
Performance
Options
Allows you to congure elds in the Performance
Options sub‑menu (for more information, see
“Advanced Menu – Performance Options“ on page 34).
SATA Operation
Allows you to congure the operating mode of the
integrated SATA hard drive controller.
AHCI: SATA is congured for AHCI mode.
•
RAID: SATA is congured for RAID mode.•
SATA HARD
DRIVE 1
Displays the installed primary SATA hard drive model.
SATA HARD
DRIVE 2
Displays the installed secondary SATA hard drive
model.
Adapter
Warnings
Allows you to choose if the computer should display
warning messages when you use AC adapters that are
not supported by your computer.
Disabled: BIOS will not detect unsupported AC
•
adapters and will not display any message to
screen.
Enabled : BIOS will detect unsupported AC adapters
•
and display an error to screen.
Charger
Behavior
Allows you to enable or disable battery charging.
Primary Display
Allows you to choose a primary display.
Advanced Menu – Performance Options
Overclocking
Feature
Allows you to enable or disable the global overclocking
feature.
Disabled: e overclocking feature is disabled.
•
Enabled: Displays additional overclocking options.•
Non-Turbo
Flex Support
Allows you to modify the CPU ex ratio with Turbo Mode
disabled.
Flex Ratio
Override
Appears when Non‑Turbo Flex is enabled and allows
you to specify the ex ratio for all CPU cores.
Extreme Edition
Allows Extreme Edition CPUs to adjust the ex ratio in
a Turbo Mode environment that allows each individual
core ratio to be modied.
Extreme Edition
Core Ratio
Limits
Allows you to modify the ex ratio of individual cores
physically present in the CPU.
Memory Override
Support
Allows you to enable or disable the memory override
option support.
Disabled: e memory override support is disabled.
•
Enabled: Displays additional memory override •
support options.
Memory
Voltage
Allows you to modify memory voltage.
Memory
Frequency
Allows you to modify memory frequency.

Alienware M18X Specifications

General

Bus type	DMI
Stepping	E1
Tjunction	105 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-3630QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	PGA988
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	24
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM76
Memory slots	4x SO-DIMM
Internal memory	12 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
HDD size	2.5 \
HDD capacity	500 GB
HDD interface	SATA
Storage media	HDD
Optical drive type	Blu-Ray ROM
Card reader integrated	Yes
Total storage capacity	1000 GB
Compatible memory cards	Memory Stick (MS), MMC, MMC+, MS PRO, SD, SDHC, SDXC
Number of HDDs installed	2
Display surface	-
Display diagonal	18.4 \
Native aspect ratio	16:9
Type	PC
Power supply type	AC/DC
Wireless technology	Wi-Fi
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
On-board graphics card ID	0x166
Discrete graphics card model	NVIDIA® GeForce® GTX 675M
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	HD
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	3.0+HS
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	1
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Keyboard number of keys	82
Operating system installed	Windows 8
Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Gaming
Battery life (max)	- h
Number of battery cells	12
Processor code	SR0UX
Processor ARK ID	71459
Processor package size	37.5 x 37.5 (rPGA988B) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Cables included	AC
AC adapter power	330 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V

Weight and Dimensions

Depth	322 mm
Width	436 mm
Weight	5410 g
Height (rear)	54.2 mm
Height (front)	53 mm
Depth (imperial)	12.68 \
Width (imperial)	17.17 \
Height (rear) (imperial)	2.13 \
Height (front) (imperial)	2.09 \
