64
CHAPTER 7: SPECIFICATIONS
Touch Pad
X/Y position resolution
(graphics table mode)
240 cpi
Size
Height 56.00 mm (2.20 inches) sensor-active area
Width 99.5 mm (3.92 inches) rectangle
Camera
Camera resolution 3.0 megapixel
Video resolution 2048 x 1536
Diagonal viewing angle 60°
Battery
12-cell “smart” lithium ion (96 Whr)
Height 30.2 mm (1.19 inches)
Width 174.0 mm (6.85 inches)
Depth 133.3 mm (5.25 inches)
Weight 0.65 kg maximum (1.43 lb)
Voltage
12 VDC ‑ 16.8 VDC
Battery
Operating time battery operating time varies depending on
operating conditions and can be signicantly
reduced under certain power‑intensive
conditions.
Life span (approximate) 300 discharge/charge cycles
Temperature range
Operating 0° to 50°C (32° to 122°F)
Storage –20° to 60°C (–4° to 140°F)
Coin‑cell battery CR-2032
AC Adapter
Type 240 W/330 W
Input voltage 100-240 VAC
Input current (maximum)
240 W 3.50 A
330 W 4.40 A
Input frequency 50 Hz-60 Hz
