Alimak ALC II User Manual

Landings ARE stored into the system
Calibration drive from inside of the car when lift is located at
bottom landing:
The displays show:
(if 5 landings are programmed into the system).
– Press Up button and the lift will accelerate upward until it
has left the reference cam, then it decelerates and stops.
– The lift will automatically move down in slow speed and just
before it reaches the reference cam it will reduce the speed to
crawling speed. The lift continues in crawling speed down to
the bottom landing.
The reference level is now programmed into the system.
The system is now back into normal mode.
Direct the lift to the desired landing.
The display shows:
Calibration drive from inside of the car when lift is located
somewhere above the bottom landing:
The displays show:
(if the number of programmed landings is 5).
– Press Down button and the lift will move downwards until it
reaches the reference cam, then it decelerates and stops.
– The lift will automatically accelerate upwards until it has
left the reference cam, then it decelerate and stops.
– The lift will once again automatically start and move down in
slow speed and just before it reaches the reference cam it will
reduce the speed to crawling speed. The lift continues in
crawling speed down to the bottom landing.
ALIMAK 335052 - 1/09
A 26
CD and 5 flash alternately
on the display for the
single system.
alternatively . . .
. . . or ’’0’’ for
permanent lifts
CD and 5 flash alternately
on the display for the
single system.
0 lights up on the display
for the single system.
Applicable for ALC II software version 3.29 and later versions ONLY!
. . . or with joystick . . .
