INSTALLATION
1. LOCATION: This machine should be installed
by only qualified technicians. The machine
should be set upon a solid level surface where
it will not be affected by strong winds, rain, or
snow. Install the machine considering the
direction of the exhaust. DO NOT DIRECT
EXHAUST TOWARD ANY COMBUSTIBLE OR
HEAT SENSITIVE MATERIAL. Install the
machine considering . locations of electrical
connections, venting, and maintenance. All
wiring and electrical connections should
comply with the National Electrical Code (NEC)
and with local codes and practices. Use the
chart on the next page for your cord selection.
2. LOCAL CODES: Installation and servicing
must only be performed by qualified personnel
and must conform to local codes and
ordinances.
WARNING: ELECTRIC
SHOCK HAZARD
3. ELECTRICAL: Connect the machine to an
electrically grounded circuit that is fuse or
circuit breaker protected. Do not use any type
of adapter. If the correct type of receptacle is
not available, have one installed by a qualified
electrician.The circuit must match that
specified in the ELECTRICAL section under
MODEL SPECIFICATIONS.
4. EXTENSION CORD: The use of an extension
cord that has undersize wire compared to the
amp draw of your machine will adversely limit
the starting load carrying abilities of the motor
and machines performance. Use only 3-wire
extension cords that have 3-prong plugs and
3-pole cord connectors that accept the plug
from the product. Use only extension cords
that are intended for outdoor use. These
extension cords are identified by a marking
“Acceptable for use with outdoor appliances;
store indoors while not in use.” Use only
extension cords having an electrical rating not
less than the rating of the product. Do not use
damaged extension cords. Use an extension
cord in good repair free of frays or cracks in
the outer covering. Do not abuse extension cord
and do not yank on any cord to disconnect.
Keep cord away from heat and sharp edges.
Always disconnect the extension cord from the
receptacle before disconnecting the product
from the extension cord.
WARNING: To reduce risk of electrocution,
keep all connections dry and off the ground.
Do not touch plug with wet hands.
CHART FIGURES ARE BASED ON NOT
MORE THAN 100 FOOT
(Based on Ambient Temperature of 86°F (30°C).
*Use Amp Draw indicated the same or higher than
your machine output
EXAMPLE: Machine Amp Draw 51, use 55 (2
Conductor).
The thermostat type of cord shall be C, PD, E, EO,
EN, S, SO, SRD, SJ, SJO, SV, SVO, SP.
The thermoset plastic types shall be ET, ETT,
ETLB, ETP, ST, STO, SRDT, SJT, SJTO, SVT,
SVTO, and SPT.B
5. FIRE HAZARD: Keep combustible materials
away from gas machines. DO NOT allow lint
or dust collect in the burner area.
6. FUEL SUPPLY: This machine must have a fuel
supply as specified in the FUEL sectio of the
MODEL SPECIFICATIONS.
7. COLD WEATHER: As the weather becomes
colder, fuel becomes thicker and may become
so viscous that the fuel will not flow properly.
12-03-03 Z08-0443BSupersedes 10-00 Z08-00443B
4
COPPER
WIRE SIZE
MINIMUM
AWG
MACHINE AMP
DRAW*
3 CONDUCTOR
WIRES
MACHINE AMP
DRAW*
2 CONDUCTOR
WIRES
16 10 13
15 -- --
14 15 18
12 20 25
10 25 30
8 35 40
6 45 55
4 60 70
2 80 95
To Next Page
