12-03-03 Z08-00443D
6
CAUTION: Do not run the machine with the
burner switch in the on position when the
fuel tank is empty. This will cause damage to
the fuel pump and void warranty.
11. Select temperature (if so equipped)
12. Turn the burner switch to the on position.
SHUT-DOWN
1. Turn the burner switch to the off position.
2. After cool air is coming from the end of the
heater, turn the blower switch to the off
position.
3. Disconnect from the electrical supply.
MAINTENANCE SCHEDULE
DAILY
FUEL LEVEL:
Check and add as needed using a filter
screened equipped funnel.
BELTS: -
Cracks or fraying.
Belt Tension
1. Deflection for each inch of span between
pulley centers with a 6-pound force applied in
the middle of the span.
EXAMPLE: A 6-pound force applied at the
middle of an 8 inch span should produce a
deflection of 8/64 inch or 1/8 inch.
2. Belts can be tightened or loosened by
loosening the nuts holding the motor to the
motor mount. Then move motor tightening or
loosing the belt. Retighten the motor nuts after
the desired tension is reached.
FILTER, FUEL:
If contaminants are present see FUEL
FILTER insert.
Remove and Replace fuel filter per FUEL
FILTER insert.
50 HOURS
BELT TENSION:
Belt Tension.
100 HOURS
FILTER, FUEL - ELEMENT:
FUEL FILTER ELEMENT- Remove & replace
per FUEL FILTER page.
STORAGE
1. FUEL TANK—Drain and flush the tank with
clean fuel oil. DO NOT use gasoline or water.
To prevent rusting from condensation, refill the
tank with the fuel specified using a filter screen
equipped funnel.
2. BLOWER—Clean each season as needed
DEFLECTION
SPAN
