3500W Generator
16
Assembly
Unpacking
1. Remove the generator and loose parts box from the carton.
2. Compare the accessory with the inventory list below.
Loose Parts (Wheel kit and handle)
Check all loose parts against the following list. Contact your dealer toll free at 888.896.6881
if any of the loose parts shown are not included with your generator
Hardware Check:
Your Hardware Kit should include:
1) 1 Handle with bolt and bracket
2) 6 (six) axle shaft bolts and nuts
3) 2 (two) 8mm bolts, (6mm x 1.0) thread
4) 2 (two) 10mm Nuts (6mm x 1.0) thread
5) 2 (two) rubber bushings with 2 nuts
6) 2 (two) axle shaft
7) 2 (two) washers
8) 2 (two) cotter pins
9) 4 (four) leg bolts and nuts
10) 1 (one) generator leg
11) 2 (two) wheels (not shown)
1
9
3
10
4
2
5
6
7
8
