All-Power APG3002S User Manual

3500W Generator
Control box assy.
47
APA Part No.
Description
Part No.
Q
APG3002S-Q-01-JD ENGINE SWITCH ASSY. JD3000-1-Q-01
APG3002S-Q-02-JD OIL ALERT LAMP JD3000-1-Q-02
APG3002S-Q-03-JD CONTROL PANEL COMP. JD3000-1-Q-03
APG3002S-Q-04-JD 120V RECEPTACLE JD3000-1-Q-04
APG3002S-Q-05-JD DC 12V OUTPUT JD3000-1-Q-05
APG3002S-Q-06-JD EARTH TERMINAL SCREW JD3000-1-Q-06
APG3002S-Q-07-JD CONTROL PANEL BACK BOX JD3000-1-Q-07
APG3002S-Q-08-JD CIRCUIT PROTECTOR(8A) JD3000-1-Q-08
APG3002S -Q-09-JD CIRCUIT PROTECTOR(20A) JD3000-1-Q-09
1
2
3
4
5
5
2
6
7
9
8
4
