Allegion LCN User Manual

E 78
July 2016
Specification guide
Prefix Function
LCE 9130 Pull ........................................................ 65006
9140 Push ....................................................... 65007
1. Prefix
All codes are prefixed with...................................................................................................................... LCE
2. Function
Select the desired function - e.g. push .................................................................................................... LCE65007
Specifications
Static holding force 680kg
Input voltage 12~24 VDC
Current draw 250mA@12VDC
125mA@24VDC
Latch cavity length 39mm
Latch cavity width 18mm
Door clearance >=3mm
Weight 650 kg
Depth of latch tongue 12/15mm (with door gap 3mm)
Strike lip 15mm
Operating temperature -20°C to 60°C
Monitoring Door position switch (DPS)
30VDC, 0.5A
Lock position switch (LPS)
30VDC, 2A
Fail safe Interchangeable with or without
monitoring
Fail secure Interchangeable with or without
monitoring
Extension lip option 1 25mm
Extension lip option 2 50mm
Certifications C-Tick Certified, CE approved
Warranty 5 year
Specifications
Housing 229mm x 32mm x 38mm
Electrical ratings EPT 2
Two 18 gauge wires up to 2 amps @ 24VDC,
with a 16 amps maximum surge
EPT 10
Ten 24 gauge wires, up to 1 amp @ 24VDC,
with a 16 amps maximum surge
Door thickness 44mm minimum
Warranty 1 year
