Allen-Bradley 1398 ULTRA Plus Series User Manual

Publication 1398-5.1 — January 2000
3-14 Wire the ULTRA Plus PDM Components
Figure 3.9
External Shunt Wiring Examples
TB2-1
R1 R2
TB2-1
TB2-3
1 - 200W Unit Configuration*
200 Watts
TB2-1
TB2-3
4 - 200W Unit Configuration*
800 Watts
9 - 200W Unit Configuration*
1800 Watts
R1
R1 R2
R3 R4
TB2-1
TB2-3
R1 R3
R4 R6
R7 R9
R2
R5
R8
NOTES:
Uses 200W units p/n 9101-1079
*Configuration good for all ULTRA Plus PDMs
TB2-1
TB2-3
R1
TB2-3
NOTES:
Uses 900W units p/n 9101-1674
*Configuration good for 1398-PDM-075,150, and 150B units
**Configuration good for 1398-PDM-150 and 150B units only
1 - 900W Unit Configuration*
900 Watts
2 - 900W Unit Configuration**
1800 Watts
