Rockwell Automation Publication CNET-IN005A-EN-P - May 2011 7
Chapter
1
Install a 1756 ControlNet Communication
Module
Topic Page
ControlLogix-XT Systems 9
Redundant Media 10
Installation Summary 10
Determine Module Slot Location 10
Set the Node Address 11
Install the Module 12
Connect the Module to a ControlNet Network 13
Remove the Module 15
Install the EDS File 17
Connect a Programming Terminal to the Network with a
1786-CP Cable
17
Connect to the Module via the USB Port 18
ATTENTION: Environment and Enclosure
This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications
(as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating.
This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR 11. Without appropriate
precautions, there may be difficulties with electromagnetic compatibility in residential and other environments due to
conducted and radiated disturbances.
This equipment is supplied as open-type equipment. It must be mounted within an enclosure that is suitably designed for
those specific environmental conditions that will be present and appropriately designed to prevent personal injury
resulting from accessibility to live parts. The enclosure must have suitable flame-retardant properties to prevent or
minimize the spread of flame, complying with a flame spread rating of 5VA, V2, V1, V0 (or equivalent) if non-metallic. The
interior of the enclosure must be accessible only by the use of a tool. Subsequent sections of this publication may
contain additional information regarding specific enclosure type ratings that are required to comply with certain product
safety certifications.
In addition to this publication, see the following:
• Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1,for additional installation requirements
• NEMA Standard 250 and IEC 60529, as applicable, for explanations of the degrees of protection provided by
enclosures
To Next Page
