Rockwell Automation Publication 1769-IN028I-EN-P - July 2020 31
Compact I/O Expansion Power Supplies
Surge transient immunity IEC61000-4-5
±2 kV line-line (DM)
and ±4 kV line-earth
(CM) on AC power
ports
±500V line-line
(DM) and ±500V
line-earth (CM) on
24V DC PWR OUT
ports
±500 V line-line
(DM) and ±1 kV line-
earth (CM) on DC
power ports
±2 kV line-line (DM)
and ±4 kV line-earth
(CM) on AC power
ports
±500 V line-line (DM) and
±1 kV line-earth (CM) on
DC power ports
Conducted RF Immunity IEC61000-4-6 10V rms with 1 kHz sine-wave 80% AM from 150 kHz...80 MHz
Voltage variation
IEC 61000-4-11
30% dips for 1 period
at 0° and 180° on AC
supply ports
60% dips for 5 and 50
periods on AC supply
ports
±10% fluctuations
for 15 min on AC
supply ports
>95% interruptions
for 250 periods on AC
supply ports
N/A
30% dips for 1 period
at 0° and 180° on AC
supply ports
60% dips for 5 and 50
periods on AC supply
ports
±10% fluctuations
for 15 min on AC
supply ports
>95% interruptions
for 250 periods on AC
supply ports
N/A
Voltage variation
IEC 61000-4-29
N/A
10 ms interruption
on DC supply ports
N/A
10 ms interruption on DC
supply ports
(1) Catalog numbers followed by a “K” indicate a conformal coating option.
Environmental Specifications (Continued)
Attribute
1769-PA2,
1769-PA2K
(1)
1769-PB2,
1769-PB2K
1769-PA4,
1769-PA4K
1769-PB4,
1769-PB4K
