Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 129
Appendix B
Accessories and Dimensions
Product Selection
Table 19 - Catalog Number Description
22C – B 024 N 1 0 3
Drive Dash Voltage Rating Rating Enclosure HIM Emission Class Comm Slot
Table 20 - PowerFlex 400 Drives
Drive Ratings Catalog Number Frame
Size
Input Voltage Normal Duty Output Current (Amps)
kW HP 45°C 50°C
240V 50/60 Hz
3-Phase
2.2 3.0 12 12 22C-B012N103 C
3.7 5.0 17.5 17.5 22C-B017N103 C
5.5 7.5 24 24 22C-B024N103 C
7.5 10 33 33 22C-B033N103 C
11 15 49 49 22C-B049A103 D
15 20 65 65 22C-B065A103 D
18.5 25 75 75 22C-B075A103 D
22 30 90 81 22C-B090A103 D
30 40 120 120 22C-B120A103 E
37 50 145 130 22C-B145A103 E
