Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 179
Metasys N2 Appendix F
BO 12 Ref Sel 1 Logic Command bit 12 BO
14
13 12
00 0=No Command
001=P038 [Speed Reference]
010=A142 [Internal Freq]
011=Comm - Address 8193
(1)
100=A143 [Preset Freq 0]
101=A144 [Preset Freq 1]
110=A145 [Preset Freq 2]
111=A146 [Preset Freq 3]
BO 13 Ref Sel 2 Logic Command bit 13
BO 14 Ref Sel 3 Logic Command bit 14
BO 15 MOP Dec Logic Command bit 15 Decrement Not Decrement
BO 16 Pnl Lock Lock-out Drive Front Panel Lock Unlock
BO 17 Digital Out 1 Relay #1 on Drive
(Drive Terminal R1, R2, R3)
On Off
BO 18 Digital Out 2 Relay #2 on Drive
(Drive Terminal R4, R5, R6)
On Off
BO 19 Opto Out Terminal #19 On Off
(1) See Writing (06) Reference on page 170.
Table 43 - Analog Outputs
Network Point Name Description Units Min/Max
Type
(NPT)
Address
(NPA)
AO 1 Reference Reference % 0/100
AO 2 Accel 1 P039 [Accel Time 1] Secs 0.0/600.0
AO 3 Decel 1 P040 [Decel Time 1] Secs 0.0/600.0
AO 4 Mtr OL Current P033 [Motor OL Current] A 0.0/Rated x 2
AO 5 PID Setpoint A157 [PID Setpoint] % 0/100
AO 6 Analog Out 1 Drive Analog Output #1 (T084) % –
AO 7 Analog Out 2 Drive Analog Output #2 (T087) % –
AO 8 Write Param # Param. number to write in AO 9 – 0...Max Param.
AO 9 Write Value Write value of param. selected by AO 8 Based on AO 8 selected param.
AO 10 Read Param # Param. number to read in AI 9 – 0...Max Param.
AO 11 User Out 1 User-defined Output 1
(Param. selected via ADI 5)
Varies by the parameter selected.
AO 12 User Out 2 User-defined Output 2
(Param. selected via ADI 6)
AO 13 User Out 3 User-defined Output 3
(Param. selected via ADI 7)
AO 14 User Out 4 User-defined Output 4
(Param. selected via ADI 8)
Table 42 - Binary Outputs
Network Point Name Description ON (“1”) OFF (“0”)
Type
(NPT)
Address
(NPA)
