Rockwell Automation Publication 2711P-UM006E-EN-P - January 2017 163
Chapter 8
Troubleshooting
Status Indicators
The terminals have two status indicators to isolate operating anomalies:
• COMM indicator (green) for communication
• FAULT indicator (red) for hardware and firmware faults
Figure 25 - Status Indicators
Topic Page
Status Indicators 163
Terminal Does Not Start Properly 164
Start-up Messages and Codes 166
Check Terminal Components 168
Ethernet Connection 169
Program Launcher ActiveX Control 170
Application Does Not Run 170
Configuration Mode Access 170
File System Errors 171
Advanced Diagnostics 171
Access Maintenance Operations 172
Restore Factory Defaults 174
COMM
FAULT
DEFAULT
RESET
FAULT
COMM
DEFAULT
RESET
FAULT
COMM Indicator
FAULT Indicator
FAULT
COMM
