24 Rockwell Automation Publication 2711P-UM006E-EN-P - January 2017
Chapter 1 Overview
Table 18 - Secure Digital (SD) Cards
Cat. No. Terminal Model Description
1784-SD1
All terminals
1 GB Secure Digital (SD) card
1784-SD2 2 GB Secure Digital (SD) card
2711C-RCSD USB to SD adapter for secure digital card (SD)
Table 19 - CCFL Backlight Replacements
(1)
(1) These CCFL-backlight replacement catalog numbers do not apply to LED displays.
Cat. No. Terminal Model Series
Number of CCFL
Backlights
2711P-RL7C
700
A and B 1
2711P-RL7C2 C and D 1
2711P-RL10C
1000
A1
2711P-RL10C2 B and C 1
2711P-RL12C
1250
A and B 2
2711P-RL12C2 C 1
2711P-RL15C 1500 B 2
Table 20 - Antiglare Overlays
Cat. No.
(1)
(1) Three overlays are shipped with each catalog number.
Terminal Model
Operator Input
Keypad Touch Key/Touch
2711P-RGB4 400 grayscale or color • •
2711P-RGK6
600 grayscale or color
••
2711P-RGT6 •
2711P-RGK7
700 color
••
2711P-RGT7 •
2711P-RGK10
1000 color
••
2711P-RGT10 •
2711P-RGK12
1250 color
••
2711P-RGT12 •
2711P-RGK15
1500 color
••
2711P-RGT15 •
Table 21 - Solar Visor
Cat. No. Terminal Model Description
2711P-RVT12 1250 Solar visor for 1250 high-bright display module,
cat. no. 2711P-RDT12H
