Allen-Bradley ControlNet PLC-5 Installation Instructions

Publication 1785-IN022C-EN-P - September 2005
Firmware Update Instructions for Ethernet, Enhanced and ControlNet PLC-5 Programmable Controllers 5
5. Locate and document the controller’s hardware Ethernet address.
The address is on the circuit board label toward the back of the
controller.
6. If applicable, disconnect the coprocessor or Ethernet Interface sidecar
module.
7. Reinstall the controller into the chassis.
8. Apply power to the controller.
9. Through the Ethernet port, use either a switch, hub or crossover cable
to connect the computer to the controller. Make sure the TCP/IP is
configured and running on the personal computer.
10. Assign the controller’s IP address by going online with the controller via
DH+ or serially. Use the channel configuration screen to configure the
IP address for Channel 2 (uncheck the BOOTP enabled box).
11. Turn the controller keyswitch to PROGRAM mode.
Allen-Bradley Motors

Allen-Bradley ControlNet PLC-5 Specifications

General

Manufacturer	Allen-Bradley
Network Type	ControlNet
Programming Software	RSLogix 5
Product Type	PLC
Communication Ports	ControlNet, DH+
Programming Languages	Ladder Logic
Operating Temperature	0°C to 60°C (32°F to 140°F)
Relative Humidity	5% to 95% (non-condensing)
Processor Type	PLC-5 Processor
Power Supply	24V DC
