FLEX I/O Digital Input and Output Modules w/ Diagnostics 11

Publication 1794-IN096C-EN-P - August 2015

Wiring Connections for 1794-OB16D

(use with 1794-TB2, 1794-TB3, or 1794-TB3S terminal base units)

Output Output Terminal Common Terminal

Output 00 A-0 B-17

Output 01 A-1 B-18

Output 02 A-2 B-19

Output 03 A-3 B-20

Output 04 A-4 B-21

Output 05 A-5 B-22

Output 06 A-6 B-23

Output 07 A-7 B-24

Output 08 A-8 B-25

Output 09 A-9 B-26

Output 10 A-10 B-27

Output 11 A-11 B-28

Output 12 A-12 B-29

Output 13 A-13 B-30

Output 14 A-14 B-31

Output 15 A-15 B-32

+V DC C-34 and C-51 (1794-TB2) (Power Terminals are internally connected in the

terminal base unit.

C-34...C-51 (1794-TB3, -TB3S) (Power terminals are internally connected in the

terminal base unit.

Common B-16...B-33 (Common terminals are internally connected in the terminal base unit.
