16 Micro850 48 Point Programmable Controllers
Publication 2080-IN008C-EN-P - August 2017
Input Specifications
Attribute 2080-LC50-48AWB 2080-LC50-48QWB / 2080-LC50-48QVB /
2080-LC50-48QBB
120V AC Input High Speed
DC Input
(Inputs 0…11)
Standard DC Input
(Inputs 12 and
higher)
Number of inputs 28 12 16
Input group to backplane
isolation
Verified by the
following dielectric
tests: 1950V AC for 2 s
150V working voltage
(IEC Class 2 reinforced
insulation)
Verified by the following dielectric tests:
720V DC for 2 s
50V DC working voltage (IEC Class 2
reinforced insulation)
Voltage category 110V AC 12/24V sink/source (standard)
24V sink/source (high-speed)
Operating voltage range 132V, 60Hz AC max 16.8…26.4V DC
@ 65°C (149°F)
16.8…30.0V DC
@ 30°C (86°F)
10…26.4V DC @
65°C (149°F)
10…30.0V DC @
30°C (86°F)
Off-state voltage, max 20V AC 5V DC
Off-state current, max 1.5 mA 1.5 mA
On-state current, min 5 mA @ 79V AC 5.0 mA @ 16.8V
DC
1.8 mA @ 10V DC
On-state current, nom 12 mA @ 120V AC 7.6 mA @ 24V DC 6.15 mA @ 24V DC
On-state current, max 16 mA @ 132V AC 12.0 mA @ 30V DC
Nominal impedance 12 k @ 50 Hz
10 k @ 60 Hz
3 k 3.74 k
IEC input compatibility Type 3
Inrush current, max 250 mA @ 120V AC –
Input frequency, max 63 Hz –
For 24V AC specifications, refer to the Micro830 and Micro850 User Manual,
publication 2080-UM002
.
