Micro850 48 Point Programmable Controllers 17
Publication 2080-IN008C-EN-P - August 2017
Output Specifications
Attribute 2080-LC50-48AWB /
2080-LC50-48QWB
2080-LC50-48QVB / 2080-LC50-48QBB
Relay Output High Speed
Output
(Outputs 0...3)
Standard Output
(Outputs 4 and
higher)
Number of outputs 20 4 16
Output voltage, min 5V DC, 5V AC 10.8V DC 10V DC
Output voltage, max 125V DC, 265V AC 26.4V DC 26.4V DC
Load current, min 10 mA
Load current,
continuous, max
2.0 A 100 mA (high-speed
operation)
1.0 A @ 30 °C
0.3 A @ 65 °C
(standard operation)
1.0 A @ 30 °C
0.3 A @ 65 °C
(standard operation)
Surge current, per point See Relay Contacts
Ratings on page 17
4.0 A for 10 ms every 1 s @ 30 °C; every 2 s
@ 65 °C
(1)
(1)
Applies for general purpose operation only. Does not apply for high-speed operation.
Current, per common, max 5A – –
Turn on time/
Turn off time, max
10 ms 2.5 s0.1 ms
1 ms
Relay Contacts Ratings
Maximum Volts Amperes Amperes
Continuous
Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A 2.0 A 1800V A 180V A
240V AC 7.5 A 0.75 A
24V DC 1.0 A 1.0 A 28V A
125V DC 0.22 A 0.22 A
