Allen-Bradley PanelView C400

PanelView Component HMI Terminals 7
Publication 2711C-IN001H-EN-P - July 2014
PanelView Component C400 Terminal
Item Description Item Description
1 Function keys, keypad, or touch display 4 USB device port
2 24V DC power input 5 RS-232 serial port
3 RS-422 and RS-485 port 6 USB host
Item Description Item Description
1 Touch display, function keys 7 24V DC power input
2 Power status LED
(1)
(1)
The Power Status LED is red when in screen saver or dimmer mode and green when in normal (operational) mode.
8 USB device port
3 RS-422 and RS-485 port 9 USB host port
4 RS-232 serial port 10 Replaceable real-time clock battery
5 Mounting slots 11 Diagnostic status indicator
6 10/100 MBit Ethernet port
1
3
4
5
6
5
9
10
2
11
7
8
