PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules
The table shows indicator states if the terminal powers on and stops during startup.
Check the Display
If the terminal display is dim or unreadable:
• Check the brightness setting of the display. From Configuration mode on the terminal,
access Terminal Settings>Display Intensity.
• Check the Screen Saver settings. The backlight may be turning off or dimming the
display unexpectedly. From Configuration mode on the terminal, access Terminal
Settings>Display>Screen Saver.
Indicator States If the Terminal Stops During Startup
Fault (Red)
Indicator
Comm (Green)
Indicator
Description
Blinking
(1)
(1) Blinking red indicates a recoverable error.
Off
Last firmware download failed.
Reload firmware using Firmware Upgrade Wizard (FUW) utility.
Blinking
EBC boot loader firmware failed or is missing.
Reload firmware using Firmware Upgrade Wizard (FUW) utility.
On
Windows CE OS firmware failed or is missing.
Reload firmware using Firmware Upgrade Wizard (FUW) utility.
On
(2)
(2) Solid red indicates a nonrecoverable or fatal error.
Off
Fatal hardware error occurred.
Replace the logic module.
Blinking
Fatal hardware error in display.
Replace the display module.

Allen-Bradley PanelView Plus 1000 Specifications

General

Display Size	10.4 inches
Resolution	640 x 480 pixels
Touchscreen	Analog resistive
Operating System	Windows CE
Memory	64 MB RAM
Storage	64 MB Flash
Communication Ports	Ethernet, RS-232, USB
Input Voltage	24V DC
Display Type	Color TFT
Processor	XScale
Enclosure	NEMA 4X
Operating Temperature	0°C to 50°C
