Allen-Bradley PanelView Plus 1000 Installation Instructions

28 Rockwell Automation Publication 2711P-IN001J-EN-P - April 2018
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules
Startup Error Messages
When an error occurs, the terminal displays an error number with a text message. The word
ERROR! appears under the message in different languages.
Error # Message Description Recommended Corrective Action
1 RAM Test RAM test failure.
Reset the terminal. If error persists, reseat the SO-DIMM RAM
module. If error still persists, replace the logic module.
23 Internal CF
Error programming the
new OS firmware to
internal CompactFlash
card.
Reload the firmware. If error persists, replace the internal
CompactFlash card. If error still persists, replace the logic
module.
24 CRC Check
Checksum of the OS
firmware failed.
Reload the firmware. If error persists, replace the internal
CompactFlash card. If error still persists, replace the logic
module.
30 Watchdog Test Watchdog test failure. Reload the firmware. If error persists, replace the logic module.
31 Stuck Key Function key failure.
Check that nothing is pressed against a key. Reset the terminal
without key presses. If error persists, replace the display
module.
31.5 Stuck Touch Touch screen failure.
Check that nothing is pressed against the touch screen. Reset
the terminal without pressing the touch screen. If error persists,
replace the display module.
32 Battery Test Battery failure. Replace the battery. If error persists, replace the logic module.
33.5 NVRAM Access
Nonvolatile memory
failure.
Upgrade the system firmware to revision 3.10.03 or later.
40 EXE Check
System OS firmware is
missing or corrupt.
Reload the firmware. If error persists, replace the internal
CompactFlash card. If error still persists, replace the logic
module.
50 External CF
Error loading the OS
firmware from the
external CompactFlash
card.
Reload the firmware. If error persists, replace the external
CompactFlash card and attempt the firmware upgrade again.
# Displayed Message
ERROR! FEHLER! ERREUR! ERRORE!

Allen-Bradley PanelView Plus 1000 Specifications

General

Display Size	10.4 inches
Resolution	640 x 480 pixels
Touchscreen	Analog resistive
Operating System	Windows CE
Memory	64 MB RAM
Storage	64 MB Flash
Communication Ports	Ethernet, RS-232, USB
Input Voltage	24V DC
Display Type	Color TFT
Processor	XScale
Enclosure	NEMA 4X
Operating Temperature	0°C to 50°C
