Allen-Bradley PowerFlex 20-750-20COMM User Manual

116 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 3 Lift and Mount the Drive
Figure 77 - Bus Bar Dimensions (Common DC Input)
(1) The UPS rail is only installed when the P30 UPS Control Bus option is selected.
Dimensions are in millimeters and (inches).
369
(14.5)
511
(20.1)
671
(26.4)
841
(33.1)
1006
(39.6)
1171
(46.1)
1854
(73.0)
125
(4.9)
776
(31.0)
839
(33.0)
1436
(57.0)
1499
(59.0)
PE
PE
DC+
DC-
U / T1
V / T2
W / T3
Control Rail
UPS Rail
(1)
