Allen-Bradley PowerFlex 20-750-APS User Manual

112 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 3 Lift and Mount the Drive
Figure 73 - IP54, NEMA 12, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
(Enclosure Codes K and Y)
IP54, UL Type 12, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
(Enclosure Code J)
800 mm Deep Drive with Wiring Bay.
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
270
(10.6)
➊
➋
➊
➋
76
(3.0)
➊
➋
270
(10.6)
127
(5.0)
76
(3.0)
ø18.0
(0.71)
742
(29.2)
43
(1.7)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
69
(2.7)
1269
(50.0)
1500
(59.1)
1731
(68.1)
200
(7.9)
440
(17.3)
440
(17.3)
440
(17.3)
1269
(50.0)
1500
(59.1)
1731
(68.1)

Allen-Bradley PowerFlex 20-750-APS Specifications

General

Model	20-750-APS
Category	Controller
Enclosure Type	Open Type
Series	PowerFlex 750
Product Type	AC Drive
Communication Protocols	EtherNet/IP
Output Current	4.0 A
Frequency	50/60 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Short Circuit
