Chapter 4 Power Wiring
Table 8 - Wall Mount Frames 6 and 7 Power Terminal Block
Table 9 - Wall Mount Frames 1…7 PE Grounding Stud
Frame Maximum Lug
Width
(1)
(1) Lugs are supplied by the user.
Recommended
Torque
Terminal Bolt Size Recommended Tool
6 34.6 mm (1.36 in.) 11.3 N•m (100 lb•in) M8 x 1.25 13 mm Hex Socket
7 43.5 mm (1.71 in.) 11.3 N•m (100 lb•in) M8 x 1.25 13 mm Hex Socket
Frame Recommended Torque Terminal Bolt/Screw Size Recommended Tool
1 1.36 N•m (12 lb•in) M4 T20 hexalobular (Torx)
#1 Flat Screwdriver
2 1.36 N•m (12 lb•in) M4 7 mm Hex Deep Socket
3 3.4 N•m (30 lb•in) M6 10 mm Hex Deep Socket
4 3.4 N•m (30 lb•in) M6 10 mm Hex Deep Socket
5 3.4 N•m (30 lb•in) M6 10 mm Hex Deep Socket
6 11.3 N•m (100 lb•in) M8 13 mm Hex Socket
7 11.3 N•m (100 lb•in) M8 13 mm Hex Socket
