Allen-Bradley PowerFlex 20-750-S1 User Manual

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 189
Power Wiring Chapter 4
Drive Catalog
Number
Duty
Cycle Hp
Short Circuit Current Rating (kA)
Circuit Breaker
Only (P3)
(1)
Circuit Breaker with Input Contactor
(P3 with P11)
(1)
Molded Case Switch Only
(P5)
(2)
Molded Case Switch with Input Contactor
(P5 with P11)
(2)
600 Volt AC Input
21G…E295 LD 350 50 • 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
ND 300 50 • 18 w/600 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
HD 250 50 • 18 w/600 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E355 LD 400 50 • 18 w/601…800 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
ND 350 50 • 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
HD 300 50 • 18 w/600 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E395 LD 450 50 • 30 w/601…900 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
ND 400 50 • 18 w/601…800 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
HD 350 50 • 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E435 LD 500 50 • 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
ND 450 50 • 30 w/601…900 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
HD 350 50 • 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E460 LD 500 35 • 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
ND 500 50 • 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
HD 400 50 • 18 w/601…800 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25 • 25 w/600 A Class J fuse
21G…E510 LD 550 35 • 30 w/601…1100 A Class L fuse
• 30 w/1100 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
ND 500 35 • 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
HD 450 50 • 30 w/601…900 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse • 30 w/800 A Class L fuse
21G…E595 LD 700 50
These options are not used with these drive ratings.
ND 600 50
HD 500 50
21G…E630 LD 800 50
ND 700 50
HD 600 50
21G…E760 LD 900 50
ND 800 50
HD 700 50
continued on page 190
