Allen-Bradley PowerFlex 20-HIM-A6 User Manual

Rockwell Automation Publication 20HIM-UM001D-EN-P - February 2013 19
Installing the HIM Chapter 2
Figure 2 - Hole Pattern to Mount the 20-HIM-C6S HIM
2. Peel the protective film from the gasketed surface on the back of the HIM.
IMPORTANT
Adhesive coated gasket is designed for one-time only installation.














Dimensions are in millimeters and (inches).
Front View
➌
➋
➍
➏
➎
➐
.sM
LBsIN
Mounting Panel
