Rockwell Automation Publication 20HIM-UM001D-EN-P - February 2013 13
Chapter 2
Installing the HIM
This chapter provides instructions for installing and removing the HIM.
There are two types of enhanced PowerFlex 7-Class HIM:
• NEMA Type 1 (catalog number 20-HIM-A6)
• Remote-mount NEMA Type 4X/12 (catalog number 20-HIM-C6S),
which also includes a 1202-C30 interface cable for connection to the drive
Topic Page
Installing the 20-HIM-A6 HIM
14
Installing the 20-HIM-C6S HIM
18
Removing the HIM
20
