16 PowerFlex 750-Series Products with TotalFORCE Control
Rockwell Automation Publication 750-PC100A-EN-P - December 2016
LCL Filter AC Input Fuse Locations - Frame 8 Drives and Bus Supplies
LCL Filter AC Input Fuse Locations - Frame 9…12 Drives and Bus Supplies
Power Module DC Link Fuse Locations - Frame 8…12 Drives and Bus Supplies
Power Module DC Precharge Fuse Locations - Frame 8…12 Common Bus Inverters
LCL Filter AC Input Fuse
Bussman No. Cat. No. Specification Qty.
170M6463 SK-RM-ACFUSE1-F8 690/700V, 900 A 3
170M6466 SK-RM-ACFUSE2-F8 690/700V, 1250 A 3
170M6470 SK-RM-ACFUSE3-F9 690/700V, 1800 A 3
170M6471 SK-RM-ACFUSE4-F9 690/700V, 2000 A 3
170M6461 SK-RM-ACFUSE5-F8 690/700V, 700 A 3
170M6469 SK-RM-ACFUSE6-F9 690/700V, 1600 A 3
Power Module DC Link and DC Precharge Fuse
Bussman No. Cat. No. Specification Qty.
170M6467 SK-RM-DCFUSE1-F8 690/700V, 1400 A 2
170M6499 SK-RM-DCFUSE2-F8 1250/1300V, 1100 A 2
