Allen-Bradley SLC 5/05 series - Message Files

Allen-Bradley Ethernet Driver
Element Field Data Type Access
MAXO Real Read/Write
MINO Real Read/Write
UPD Real Read/Write
PV Real Read/Write
ERR Real Read/Write
OUT Real Read/Write
PVH Real Read/Write
PVL Real Read/Write
DVP Real Read/Write
DVN Real Read/Write
PVDB Real Read/Write
DVDB Real Read/Write
MAXI Real Read/Write
MINI Real Read/Write
TIE Real Read/Write
FILE Short, Word Read/Write
ELEM Short, Word Read/Write
EN Boolean Read/Write
CT Boolean Read/Write
CL Boolean Read/Write
PVT Boolean Read/Write
DO Boolean Read/Write
SWM Boolean Read/Write
CA Boolean Read/Write
MO Boolean Read/Write
PE Boolean Read/Write
INI Boolean Read/Write
SPOR Boolean Read/Write
OLL Boolean Read/Write
OLH Boolean Read/Write
EWD Boolean Read/Write
DVNA Boolean Read/Write
DVHA Boolean Read/Write
PVLA Boolean Read/Write
PVHA Boolean Read/Write
Example Description
PD14:0.SP Set point field of PD 0 file 14
PD18:6.EN Status enable bit of PD 6 file 18
Message Files
Message files are a structured type whose data is accessed by specifying a file number, an element and a field.
The default data type depends on the field being accessed. Integer fields receive a default data type of Word.
Syntax Data Type
MG<file>:<element>.<field> Depends on field
File Numbers and Elements
The following file numbers and maximum element are allowed for each model.
