ASSEMBLY INSTRUCTIONS
5
1. Secure the hanger bracket (A) to the ceiling outlet
box using hanging bracket screws and hanging
bracket washers.
Important: If attaching the fan to a sloped ceiling,
make sure open end of mounting bracket is installed
facing the roof. Do not install fan on a ceiling with a
pitch greater than 20°.
1
A
Outlet Box
Lowes.com/allenandroth
For hugger (flushmount) assembly proceed to page 6. Steps 2 and 3.
For down rod assmbly proceed to page 7 and 8. Steps 4 through 7.
To Next Page
