ASSEMBLY INSTRUCTIONS
31. Attach L-shaped brackets (Q1) to top
side beams 1/2 (E6/E4) and side
beams 1/2 (D1/D2) using bolts (AA)
and washers (BB).
Hardware Used
AA
M6
x
15 Bolt
BB
BB
Flat Washer
x 4
x 4
30. Attach decorative railings (I3/I4) to
top beam (E2) using bolts (AA) and
washers (BB).
Hardware Used
AA
M6 x
15 Bolt
BB
M6 Flat Washer
x 3
x 3
29. Attach decorative railings (I3/I4) to
top side beam (E4/E6) using bolts
(AA) and washers (BB).
Hardware Used
AA
M6 x15 Bolt
BB
M6 Flat Washer
x 2
x 2
