Page 12 | AlliedWare™ OS How To Note: EPSR
Example
1 : A Basic Ring
delete vlan=1 port=1-2
This step creates the domain, specifying that this switch is the master node. It also specifies
which VLAN is the control VLAN and which port is the primary port.
create epsr=test mode=master controlvlan=vlan1000 primaryport=1
add epsr=test datavlan=vlan2
enable epsr=test
Configure the Transit Nodes (B and C)
Each of the transit nodes has the same EPSR configuration in this example.
create vlan=vlan1000 vid=1000
add vlan=1000 port=1-2 frame=tagged
create vlan=vlan2 vid=2
The two ring ports must belong to both the control VLAN and all data VLANs.
add vlan=2 port=1-2 frame=tagged
delete vlan=1 port=1-2
5. Remove the ring ports from the default VLAN
6. Create the EPSR domain
7. Add the data VLAN to the domain
8. Enable EPSR
1. Create the control VLAN
2. Add the ring ports to the control VLAN
3. Create the data VLAN
4. Add the ring ports to the data VLAN
5. Remove the ring ports from the default VLAN
