Parts - 795 Loader
Item Part # Description Qty
Reg
1 31596 795 Main Frame Weldment 1
2 24296 Quick Attach Weldment Left 1
3 24297 Quick Attach Weldment Right 1
4 816343 Cross Tube 1
5 108827 Pin Weldment 2
6 1112 3 1 Stand Weldment 2
7 1112 3 2 Strap Stand 2
9 110907 Pin 0.625 Dia. Stand 2
10 12779 Hair Pin Clip #9 Western Wire 4
11 11144 1 Leveling Rod 1
12 112954 Pin 1.25 Dia. x 6.75 Lg 4
13 112955 Pin 1.25 Dia. x 5.00 Lg 4
14 84162 Cotter Pin 0.156 x 1.00 1
15 117371 Pin 1.25 Dia x 6.12 Lg 4
16 816082 Tube Cover 1
17 24309 3.0 Dia. x 20.75 Bucket Cylinder 2
18 24314 3.0 Dia. x 30.00 Lift Cylinder 2
20 81581 Bolt Hex 0.375Nc x 2.50 Gr5 Pl 12
21 81669 Bolt Hex 0.625Nc x 3.50 Gr5 Pl 4
22 81592 Nut Hex 0.375Nc Gr2 Pl 4
23 81344 Nut Lock (Nylon) 0.375Nc Grb Pl 16
24 81967 Nut Lock (Nylon) 0.625Nc Grb Pl 6
25 81570 Washer Flat Std. 0.375 Hs Pl 4
27 815192 795 Series Decal LHS 1
28 815193 795 Series Decal RHS 1
29 813935 Decal “Important” 1
*Part of decal replacement kit X1256
