Specifications - 795 Loader
Model number: 795
Mounting height: 43.0" (nominal)
Typical range: 40.0 to 46.0
Description Bucket Lift TSL Bucket
Bore 3.00 3.00 3.00
Rod 1.50 1.75 1.75
Stroke 20.50 30.00 22.00
A - Maximum lift height (full height): 163" (13.6')
B - Clearance with bucket dumped (full height): 137" (11.4')
C - Reach at full height: 25"
D - Maximum dump angle (full height): 32°
D - TSL max dump angle at ground: 60°
D1 - TSL dump angle at ground: 90°
F - Bucket rollback angle ground: 19°
F1 - TSL bucket rollback angle: 37°
G - Digging depth: 4"
H - Overall height in carry position: 84" (7')
R - Rollback angle at full height: 111°
R - TSL bucket rollback angle at full lift: 52°
Estimated breakout force: 5705 lbs
Estimated lift capacity: 3100 lbs
Notes:
1 - Calculated values assume 2500 psi cylinder pressure
2 - Breakout force estimated as per ASAE S301.2 - 4.1.2 (net payload applied at cutting edge)
3 - Lift capacity estimated a per ASAE S301.2 - 4.1.1 (payload applied at bucket midpoint)
3 - All pins are 1.25 diameter
